Woodpecker i-Scan Wireless Plate Scanner / Dental Equipments

The new Woodpecker phosphor plate system: intelligent, intuitive and capable of producing a clear and immediate image.Woodpecker i-Scan modern, compact, wireless plate scanner from Woodpecker comes with a 7 inch, Ultra high resolution touch screen and 25um advanced micro-spot laser scanning technology. To bring you an ultra clear, smoother, image and allow for more reliable diagnosis basis.With i-Scan you make scanning processes automatic, easy and precise. Its compact design adapts to any work environment.i-Scan allows users to capture outstanding images quickly and easily.

FEATURES:-

Powerful processing capability:

• A reliable diagnosis for dentists
• Cutting-edge 14nm FinFET LPC technology, and FPGA used as a coprocessor, enabling smoother image processing capability.

Large HD touchscreen:

• A 7 inch high resolution screen allowing dentists to obtain clearer diagnostic images.
• High quality interface makes it easy to shoot and read.

High performance:

• 8-core CPU and 14nm LPC FinFET processor
• More than 100 million data acquired.

Powerful software:

• One click installation, easy operation and versatile function.
• Professional and precise processing with intelligent image optimization, plus support is in multiple languages.
• Open software, no licensing problem
• Possibility to integrate any image format.

Flexible and compact:

• With an area of ​​only 0.13 m2, the i-Scan is powerful, complete and compact.
• It can be installed in dental clinics easily, for use directly next to the chair.

Ultra-thin and flexible plate:

• Imported ultra-thin imaging plate can be reused more than 1000 times.
• It is only 0.4 mm thick, more flexible than conventional films.
• A total of 4 intraoral imaging places of size (0-3) can be used on i-Scan, allowing different tooth positions to be photographed

TECHNICAL SPECIFICATION:-

• Primary technical parameters:
• Power adapter input: 100-240V 50/60Hz
• Power adapter output: DC 15V 3.2A
• IP imaging plate model: 0; 1; 2; 3
• Threshold contrast: 4 holes of 1.0 mm, 1.5 mm, 2.0 mm and 2.5 mm can all be distinguished
• Image uniformity:<2%
• Weight: 4.5KG
• Very thin sheets, with a thickness of 0.4 mm in four different formats: 21 x 32 mm; 23 x 39 mm; 30 x 40 mm: 26 x 53 mm.
• Resolution: 1280x800
• Touch Screen Monitor: 800 x 1280 px.

Operation environment:

• Environment temperature: 5℃ ~ 40℃
• Relative humidity: 30% ~ 75%
• Atmospheric pressure: 70kPa ~ 106kPa

 PACKAGING:-

• 1 x Main i Scan Unit
• 1 x Power Lead
• 1 x IP Imaging Plate #0
• 1 x IP Imaging Plate #1
• 2 x IP Imaging Plate #2
• 1 x Protective Barrier Envelope #0
• 1 x Protective Barrier Envelope #1
• 1 x Protective Barrier Envelope #2
• 1 x Protective Card for IP Imaging Plate #0
• 1 x Protective Card for IP Imaging Plate #1
• 2 x Protective Card for IP Imaging Plate #2
• 1 x Plate Storage Case With Clear Lid
• 1 x Lockable Metal Storage Case For i Scan Unit
• 1 x USB Software
• 1 x Wireless Dual Band Adapter with Free Driver
• 1 x Instruction Manual
• 1 x Warranty Card
