Gnatus Timex 70e Ac X-Ray Wall Mount With Scissors Arm / Dental Equipments

Gnatus Timex 70E AC X-Ray equipment is inspired by a path breaking Green Technology. Its Joints allow a rotation of 180 degrees. Its gait is smooth, precise, easy to handle and has excellent stability.

Features

•  Smooth, precise, easy to handle and has excellent stability.
•  Ergonomic digital control can be detached from the device and positioned   outside the clinic room with the Out-Box System comprising:
•  Command box
•  with 10m cable extender
•  25 time intervals ranges standards of exposure. The user can reschedule the time. 300 degree rotation with indication on the back and front side of the head.
•  Thermal protection, avoids over heating of the head, increasing its useful life and ensuring perfect functioning of the device. Rectangular Collimator reduces by 55% the total area to be irradiated.
• Cylinder protractor in its elongated and rectangular collimator allow the realization of radiographs with greater dimensional fidelity.
• Cylinder Protractor (300mm)
• Cylinder Conventional (200mm)
• Compensation chamber keeps the internal pressure of the head stable which ensures perfect functioning.
• It has an innovative command chamber in thermoplastic material with round corners.
• Pantographic type arms with higher reach, allows its use in most variable positions. It is smooth in movements and excellent stability.

Key Specifications

•  Wall Mount
•  Green Technology
•  Light, Smooth and Stable

More Information

• Nominal Tension : 127V or 220V
• Power : 1200VA
• Frequency : 50/60Hz
• Tension of charge exposure : 70kVp
• Max Current of the tube : 7mA
• Time of exposure : 60ms a 3,2s
• Cylinder : 200mm (300mm optional)
• Rectangular Collimator : 30 x 40mm
• Equivalent filter of Aluminum : 1.5mm
• Nominal Focal point value : 0.8 x 0.8mm

 Warranty

• Manufacturer/Importer warranty of 12 months applicable for this product Service and Warranty are handled by the manufacturer/importer directly for this product
